XP Series

XP Series

XP Series batteries incorporate advanced VRLA&TTP technology designed for ultra high rate performance in UPS & power supply applications with 12 years design life at 25 ℃ ambient temperature. By using strong grid and specific paste plate to insure extra durable stable performance under high rate discharge.

Features Application Specification

1. Valve Regulated Lead Acid (VRLA) Battery

2. Absorbent Glass Mat (AGM) Separators technolog for high efficiency gas absorption of up to 98%

3. Maintenance Free (no topping up)

4. No restrictions for rail, road, sea & air transport -Complies with IATA/ICAO Special Provisions A67

5. Special designed grids for optimized high power density

6. Advanced lead tin calcium alloy, reduces grid corrosion & promotes long battery life

7. Oversized partition intercell welds, providing low resistance connections & minimal power loss

8. Performance excels at high rates of discharge & recharge

9. High integrity post seal for long life

10. Vent Valve - allows the release of excess gases & prevents case rupture

11. Design according with IEC 60896-21/22:2004, etc.


  • 1. Data Centre (High Rate UPS)
  • 2. Telecommunication
  • 3. Banks & Financial Centre
  • 4. Hospital& Testing Laboratories
  • 5. Power Generation Plants
  • 6. Emergency Lighting
  • 7. Emergency Power Supply
  • 8. High Power Backup Supply
Model Rated
Voltage
W1520HrLengthWidthHeightTHWeight Terminal
V

1.67V/

cell

1.80V/

cell

mmin.mmin.mmin.mmin.kgibs
XP12-100 1292.8271646.461254.921726.771756.897.917.42T12
XP12-150 12150.0351957.681305.121646.461676.5710.222.49T6
XP12-210 12225.1552299.021385.432007.872037.9917.338.15T6
XP12-300 12324.68226010.241686.612088.192118.3124.052.92T6
XP12-350 12370.39530612.051686.612088.192118.3128.061.74T6
XP12-400 12405.7100325.512.811706.692138.392168.5031.469.24T8
XP12-490 12490.914233513.191726.7727510.8327810.944292.61T8
XP12-540 12539.015533513.191726.7727510.8327810.9442.493.49T8
XP12-740 12740.022052220.552409.452188.582248.8263.5140.02T11
XP12-810 12810.025052220.5526810.552208.662268.9072.5159.86T11
