Forklift

Product features

Main application areas

Fast charging: freely charge at maximum 1C and 2C high rate

High and low temperature resistance: achieve normal work from -20℃ to 60℃

Maintenance-free: no need maintanance of performance released at low temperature when adopted thermal management; no need manual maintenance with fully enclosed structure

Improved safety: the battery management system achieves real-time monitoring and adjustment

Efficient energy saving: up to 95% energy conversion rate with fast charging(1-2 hours of charging can meet 2-4 hours of operational use)


Oil change to lithium power and lead-acid change to lithium powered forklift matching batteries

Specification
ModelNominal Voltage(V)Nominal Capacity (Ah)Energy (Wh)Operating Voltage (V)Dimensions (mm)
Weight(kg)Download
FP24-10025.61002.56
20-29.2V340*330*28024

FP24-100 Specification.pdf

FP24-10525.61052.6820-29.2V345*245*24020

FP24-105 Specification.pdf

FP24-20025.62005.1220-29.2V495*290*26845

FP24-200 Specification.pdf

FP48-10551.21055.3740-58.4V585*328*234
50

FP48-105 Specification.pdf

FP48-6051.2603.0740-58.4V329*567*235
37

FP48-60 Specification.pdf

FP72-2873.6282.0657.5-83.95V534*278*168
19

FP72-28 Specification.pdf

FP72-4473.6443.2357.5-83.95V529*278*228
25

FP72-44 Specification.pdf
