AGM EN Series
AGM Start-Stop Battery
Contact US
| Model | Nominal | Rated | RC (min) | CCA | Approx. Dimensions | Hold | Handles | Appox. | Terminal Type | ||||
| Voltage | Capacity | (-18°C) | Down | Weight | |||||||||
| (V) | C20(Ah) | L | W | H | TH | （±0.3kg） | |||||||
| (+0/-2mm) | (+0/-2mm) | (+0/-3mm) | (+0/-3mm) | ||||||||||
| mm | mm | mm | mm | kg | Terminal | Layout | |||||||
| AGM-L1 | 12 | 40 | 61 | 400 | 207 | 175 | 190 | 190 | B13 | TS2 | 14.2 | 1 | 0 |
| AGM-L1 | 12 | 40 | 61 | 400 | 207 | 175 | 190 | 190 | B13 | TS2 | 14.2 | 1 | 1 |
| AGM-L1 | 12 | 50 | 80 | 570 | 207 | 175 | 190 | 190 | B13 | TS2 | 15.5 | 1 | 0 |
| AGM-L2 | 12 | 60 | 100 | 660 | 242 | 175 | 190 | 190 | B13 | TS2 | 18.6 | 1 | 0 |
| AGM-L3 | 12 | 70 | 120 | 760 | 278 | 175 | 190 | 190 | B13 | TS6 | 21.1 | 1 | 0 |
| AGM-L3 | 12 | 70 | 120 | 760 | 278 | 175 | 190 | 190 | B13 | TS6 | 21.1 | 1 | 1 |
| AGM-L4 | 12 | 80 | 140 | 800 | 315 | 175 | 190 | 190 | B13 | TS6 | 24 | 1 | 0 |
| AGM-L5 | 12 | 95 | 160 | 850 | 353 | 175 | 190 | 190 | B13 | TS6 | 27.3 | 1 | 1 |
| AGM-L5 | 12 | 95 | 160 | 850 | 353 | 175 | 190 | 190 | B13 | TS6 | 27.3 | 1 | 0 |
| AGM-L6 | 12 | 105 | 190 | 950 | 394 | 175 | 190 | 190 | B13 | TS6 | 30.6 | 1 | 0 |
| Model | Nominal Voltage (V) | Rated | RC (min) | CCA | Approx. Dimensions | Hold | Handles | Approx. | Terminal Type | ||||
| Capacity | (-18℃) | L | W | H | TH | Down | Weight | ||||||
| C20 (Ah) | mm | mm | mm | mm | kg | Terminal | Layout | ||||||
| AGM-L2 | 12 | 60 | 100 | 660 | 242 | 175 | 190 | 190 | B13 | TS2 | 18 | 1 | 0 |
| AGM-L3 | 12 | 70 | 120 | 760 | 278 | 175 | 190 | 190 | B13 | TS6 | 20.6 | 1 | 0 |
| AGM-L4 | 12 | 80 | 140 | 800 | 315 | 175 | 190 | 190 | B13 | TS6 | 23.6 | 1 | 0 |
| AGM-L5 | 12 | 95 | 160 | 850 | 353 | 175 | 190 | 190 | B13 | TS6 | 26.5 | 1 | 0 |
Parameter information subject to the contract, here for your reference only.
With Start-Stop vehicles, the engine is switched off during short stops for instance at traffic lights in order to save fuel and to reduce CO2 emissions by 5-10%.
Technology Focus:
In response to CO2 reduction targets set by EU that require engine to be shut off instead of idling while the vehicle is stopped, nearly all vehicle manufacturers launch start-stop platforms in Europe automotive battery.
Requirements:
Battery is required to start engine more frequently and provide energy for device support while "stop" mode Battery is integrated within a sophisticated energy and battery management system
Battery Technology:
Advanced AGM technology for: super high power and cold cranking ampere; very good charging acceptance performance; much longer cycle life compared to normal flooded car batteries.
