PLH Series
Pure Lead is used to optimize the high rate and float life，punched continuous grid strip – better metal crystal structure，and high temperature curing is used for standby application to improve cycle ability.
Contact US
Pure Lead is used to optimize the high rate and float life，punched continuous grid strip – better metal crystal structure，and high temperature curing is used for standby application to improve cycle ability.
Contact US| Model |
Rated Voltage | 10Hr | Length | Width | Height | TH | Weight | Terminal | |||||
| V | 1.80V /cell | mm | in. | mm | in. | mm | in. | mm | in. | kg | ibs | ||
| PLH40FT(A) | 12 | 38 | 298.7 | 11.76 | 97 | 3.82 | 184 | 7.24 | 184 | 7.24 | 12.5 | 27.6 | T6(M6) |
| PLH62FT(A) | 12 | 62 | 298.7 | 11.76 | 97 | 3.82 | 267 | 10.51 | 267 | 10.51 | 19.1 | 43.0 | T6(M6) |
| PLH90FT(A) | 12 | 90 | 405.4 | 15.96 | 108 | 4.25 | 287 | 11.30 | 287 | 11.30 | 28.7 | 63.3 | T8(M6) |
| PLH100FT(A) | 12 | 100 | 405.4 | 15.96 | 108 | 4.25 | 287 | 11.30 | 287 | 11.30 | 30.8 | 67.9 | T8(M6) |
| PLH110FT(A) | 12 | 110 | 559 | 22.01 | 125 | 4.92 | 227 | 8.94 | 227 | 8.94 | 36.5 | 80.5 | T8(M6) |
| PLH150FT(A) | 12 | 150 | 559 | 22.01 | 125 | 4.92 | 277 | 10.91 | 277 | 10.91 | 48.0 | 105.8 | T8(M6) |
| PLH170FT(A) | 12 | 170 | 559 | 22.01 | 125 | 4.92 | 320 | 12.60 | 320 | 12.60 | 54.2 | 119.5 | T8(M6) |
| PLH190FT(A) | 12 | 190 | 559 | 22.01 | 125 | 4.92 | 320 | 12.60 | 320 | 12.60 | 57.6 | 127.0 | T8(M6) |
| PLH210FT(A) | 12 | 210 | 559 | 22.01 | 125 | 4.92 | 328 | 12.91 | 328 | 12.91 | 60.5 | 133.4 | T8(M6) |
Parameter information subject to the contract, here for your reference only.
1.Long float life for telecommunication applications.
2.A design life up to 20 years with Pure Lead-Thin Plate and punching technologies.
3.Unique vent valve design minimizes water loss and prevents air and spark going inside.
4.Maintenance free with oxygen recombination technology.
